Purolite C100E Water Softener Resin
Purolite C100E |
List Price: US$105.00 Starting at: US$83.97 Choose Option: In order to reduce shipping costs media orders may be split into multiple boxes and ship in clear plastic bags instead of the original packaging. Bulk quantity discounts available. For bulk quantities, please call 1-866-376-2690 for price quote.
Write a review. Found a Lower Price? Request a Price Beat |
high-capacity and economical cation exchange water softening resin
Purolite C100E cation water softener resin is a high-capacity and economical ion exchange water softening resin used in new water softeners and to re-bed existing water softeners.
- gel polystyrene strong acid cation exchange resin
- economical price
- high capacity of up to 33,000 grains per cubic foot
- 8% cross-linked
- Water Quality Association Gold Seal Validated to conform to NSF/ANSI Standard 61
| Operating Conditions / Requirements: | |||||||
|---|---|---|---|---|---|---|---|
| Polymer Structure: | Polystyrene / min 8% cross-linked | ||||||
| Physical Form / Appearance: | Golden yellow spherical beads | ||||||
| Functional Groups: | Sulfonic Acid | ||||||
| Ionic Form as Shipped: | Sodium | ||||||
| Regenerant: | Sodium or Potassium chloride | ||||||
| Recommended Service Flow Rate: | 5-7.5 GPM/ft3 | ||||||
| Flow Direction: | Downward Flow | ||||||
| Backwash Flow Rate: | 5-6 GPM/ft2 | ||||||
| Typical Freeboard: | 50% | ||||||
| Recommended Bed Depth: | 30-36 Inches | ||||||
| Maximum Feed Temperature: | 120°C (248.0°F) | ||||||
| pH Range: | 0 to 14 | ||||||
| Weight: | Approx. 50 lbs per Ft3 | ||||||
| Recommended Configurations for Residential and Light Commercial Applications | |||||||
|---|---|---|---|---|---|---|---|
| Tank Size: |
8 x 44 | 9 x 48 | 10 x 54 | 12 x 52 | 13 x 54 | 14 x 65 | 16 x 65 |
| C100E Resin Volume (Cubic Feet): |
0.75 | 1.0 | 1.5 | 2.0 | 2.5 | 3.0 | 4.0 |
| Maximum Capacity @ 15 lbs of salt per CF: |
24,750 | 33,000 | 49,500 | 66,000 | 74,250 | 99,000 | 132,000 |
| Maximum Capacity @ 9 lbs of salt per CF: |
20,250 | 27,000 | 40,500 | 54,000 | 60,750 | 81,000 | 108,000 |
| Maximum Capacity @ 6 lbs of salt per CF: |
16,500 | 22,000 | 33,000 | 44,000 | 49,500 | 66,000 | 88,000 |
| Bed Depth (Inches): |
26* | 27* | 33 | 30 | 32 | 34 | 34 |
| Recommended Service Flow Rate (GPM)*: |
3.5 to 7.0 | 5.0 to 10.0 | 7.0 to 14.0 | 10 to 20 | 12 to 24 | 16 to 32 | 22 to 44 |
| Maximum Recommended Flow Rate (GPM)*: |
10 | 15 | 20 | 30 | 36 | 48 | 65 |
| Backwash Flow Rate (GPM) at 60F: |
1.7 | 2.2 | 2.7 | 3.9 | 4.6 | 5.4 | 7.0 |
* Bed Depth not optimal due to tank height.
